Pioneer

Only 4 left!

Car Audio 10-inch Single 4-ohm Voice Coil Component Subwoofer
Model: TS-A25S4
SOLD INDIVIDUALLY

PRODUCT PERFORMANCE
Continuous Power handling (RMS) - Watts: 350 W
Frequency Response: 22 Hz to 1.4 kHz
Maximum Peak Power Handling - Watts: 1,200 W
Nominal Impedance - Ohm: 4-Ohm
Sensitivity (1W/1m): 85dB
System-Type: Component
FEATURES
CarSoundFit: Yes
Cut Out dimensions: 9",23 cm
Equivalent Compliance (VAS): 23 Liters,0.8 Cu. Ft.
Free Air ResoNAnce (Fs): 39.2
Linear Excursion (Xmax): 8.7 mm,0.34"
Mounting Depth: 5",12.7cm
Port Diameter: 3",8 cm
Port Length: 6-1/2",17 cm
Recommended Ported Box Internal volume: 31.1 Liters,1.09 Cu. Ft.
Recommended Sealed Enclosure Volume: 22.6 Liters,0.8 Cu Ft
Total Speaker "Q" (Qts): 0.72
MATERIALS
Basket Material: Metal
Center Cap Material: ABS
Cone Material: Carbon and Mica reinforced Injected Molded Polypropylene - IMPP
Damper: Poly cotton Aramid
Installation Ring: Polypropylene
Magnet Material: Ferrite
Magnet Weight: 46 oz
Surround Material: Rubber
Surround Type: Rolled
Voice Coil Bobbin: Aluminum
Voice Coil Type: Single Voice Coil 4-ohm
Voice Coil wire: Copper
Wire Terminals: Push Type
